What to Expect During a New Aircond Installation
A clear walkthrough of an aircond installation: site assessment, timing, what the crew does and what to prepare, so there are no surprises.
A new aircond is a major upgrade, and the worry that comes with it is usually about the unknowns: the dust, the noise, the chance of surprise charges. A smooth installation comes down to clear communication before a single tool is lifted. This walkthrough shows you exactly how the day runs, from the first survey to the final test.
Before the Day: The Site Assessment
A proper installation never starts cold. We assess the space first, in person or via detailed photos, to plan the indoor unit position, the drainage route and the wiring.
A few things get confirmed at this stage. Manufacturers such as Daikin and Panasonic require a 50mm to 100mm gap between the ceiling and the indoor unit for proper air intake, so the mounting height is checked. The copper piping length is measured too: most standard split systems run up to about 7.5 metres without needing extra refrigerant, and stretching past that forces the compressor to work harder.
We also check the wall itself. Standard Malaysian brick walls need a 65mm diamond core drill bit for a clean penetration without cracking the plaster. The point of this assessment is one thing: an accurate, fixed quote before any drilling begins, so there are no surprises on the day. This is the groundwork for our aircond installation service.
On Installation Day
A standard back-to-back wall installation takes two to four hours in most Ipoh homes. Ceiling cassette units involve more complex access and usually need four to six hours.
Once you have approved the quote, the work follows a proven sequence.
| Step | What Happens |
|---|---|
| 1. Bracket and indoor mount | Bracket fixed at the right height, indoor unit secured |
| 2. Wall penetration | A clean 65mm hole drilled for piping and drainage |
| 3. Outdoor unit placement | Compressor positioned safely on brackets or a stand |
| 4. Copper piping connected | Lines of at least 0.61mm thickness run and flared |
| 5. Drainage routed | PVC drain piped to the exterior discharge point |
| 6. Wiring connected | Correctly rated cable connected to a dedicated breaker |
| 7. Vacuuming | System vacuumed to 500 microns for 15 minutes |
| 8. Test run and handover | Unit switched on, cooling confirmed, area cleaned |
The crew protects your floor and furniture throughout, and the plaster dust from the wall penetration is swept up before the team leaves.
No-surprises policy
Any issue found during the work, such as a hidden wall cavity that changes the pipe route, is shown to you immediately. The solution is agreed together before work continues, so you never come home to unexpected extra charges.
The Vacuuming Step Budget Installers Skip
One step separates a proper installation from a cheap one: vacuuming the refrigerant lines. We use a vacuum pump for a minimum of 15 minutes to bring the system down to 500 microns. This removes air and moisture from the pipes, and that matters because moisture left inside reacts with the refrigerant oils and causes early compressor failure. A skipped vacuum is a fault you only discover years later.
How to Prepare
A little preparation makes the day far smoother:
- Clear a 2-metre radius around the indoor wall for ladder access
- Confirm the outdoor balcony or ledge is clear for the compressor
- Cover nearby electronics and fabrics with plastic sheeting
- Keep children and pets in a separate, closed room during drilling
- Have an adult home throughout to approve any on-the-spot routing decisions
It also helps to locate your home’s distribution board in advance, since a dedicated breaker often needs to be installed for larger inverter units.
For more detail on the materials that decide how long the system lasts, read what a proper install includes, and plan for routine aircond chemical wash to keep the new unit efficient.
Aircon Service Pro Ipoh has completed more than 3,450 jobs across the Kinta Valley since 2018. Request an installation quote and we will discuss your exact cooling needs before we start.
